Lexmark T632 - Page 297

Parts catalog 7-61
4060-xxx
Assembly 27: 5-bin mailbox
Asm-
Index
Part
Number
Units Description
27-1 99A1512 1 Cover, redrive cap
2 99A1710 1 Cover, wire
3 99A1711 1 Cover, top bin
4 99A1785 2 Latch, rear access door
5 99A0104 1 Spring, upper diverter
6 99A1714 1 Door, rear access
7 99A1723 4 Shaft asm, drive
8 99A1724 1 Shaft asm, drive w/gear
9 99A1708 1 Cover, right side
10 99A1725 1 Packet, drive shaft bushing
11 99A1742 2 Sensor, 5-bin mailbox pass thru
12 99A1712 5 Tray, paper cap
13 99A1739 1 Bracket asm, bail attach w/brush
14 99A1743 1 Kit, 5-bin mailbox asm
15 99A1666 1 Label, options
16 1 Bail, order 99A1743, 5-bin mailbox asm kit
17 99A1713 5 Support, paper tray
18 99A1687 5 Stop asm, paper tray
19 99A1735 5 Flag, bin full
20 99A1737 5 Sensor, dual paper height
21 99A1736 5 Cable, dual sensor
22 99A1718 1 Cable asm, lower auto connect
23 99A1716 1 Drive asm, main DC drive
24 99A1740 1 Board asm, 5-bin mailbox system
25 99A1726 1 Frame asm, left w/clutch asm
26 99A1786 1 Gear, drive
27 99A1719 1 Cable asm, upper auto connect
28 12 Screw, board mounting PP 99A0263
29 99A1709 1 Cover, left side
