Parts catalog 7-63
4060-xxx
Assembly 27 (cont.): 5-bin mailbox
Asm-
Index
Part
Number
Units Description
27-30 99A1741 4 Spring, diverter
31 99A1727 1 Frame asm, right side
32 99A1728 4 Cam, diverter actuator
33 99A1731 4 Spring, diverter actuator
34 99A1729 4 Latch, diverter actuator
35 99A1730 4 Arbor, diverter actuator
36 99A1789 4 C-clip
37 99A1720 1 Bracket, attach
38 99A1732 4 Solenoid, diverter
39 99A1738 5 Deflector, paper exit w/brush
40 99A1722 4 Deflector, paper
41 99A1787 4 Deflector
42 99A1721 1 Deflector, paper top bin
NS 99A1734 1 Spring, static ground
NS 99A0462 1 Grease packet, IBM #23
NS 99A1715 1 Roller asm, rear access door
NS 99A1717 1 Gear, drive
NS 99A1788 1 Retainer, R-ring
