Parts catalog 7-65
4060-xxx
Assembly 28: High-capacity feeder 1
Asm-
index
Part
number
Units Description
28—1 99A0660 1 Frame, printer support frame 2
2 99A0675 3 Parts packet, screw
(printer support 2 frame mounting)
3 99A0698 2 Clamp, feed frame
4 99A0675 4 Parts packet, screw (feed frame clamp)
5 99A0691 2 Bearing, Nyliner leadscrew top
6 99A0656 1 Cover, left side
7 99A0681 4 Strip, wear
8 99A1818 1 Strip, wear dimple
9 99A0675 3 Parts packet, screw
(deflector mt 8-18 x 7/8 inch)
10 99A1829 1 Label, tray option number
11 99A0662 2 Transfer leadscrew assembly
12 99A0716 2 Bearing, leadscrew bottom
13 99A0676 4 Parts packet, nut (6-32 hinge mounting)
14 99A0677 4 Parts packet, washer (hinge mounting flat)
15 99A0677 4 Parts packet, washer (hinge mounting star)
16 99A0657 2 Hinge, door
17 99A0655 1 Door assembly, front
18 99A0658 2 Magnet, door
19 99A0650 1 Frame assembly
20 99A0661 1 Tray assembly, elevator
21 99A1806 1 Card assembly, 2000 option control
22 99A0677 4 Parts packet, washer (card asm. mounting)
23 99A0675 4 Parts packet, screw (card asm. mounting)
24 99A0392 1 Kit, door switch spring and bumper
25 99A0677 1 Parts packet, washer (door switch spring mounting)
26 99A0676 1 Parts packet, nut (door switch spring mounting)
NS 99A0690 1 Cable, optical sensor
