Parts catalog 7-67
4060-xxx
Assembly 29: High-capacity feeder 2
Asm-
index
Part
number
Units Description
29—1 99A0188 3 Guide, rear paper, use with 99A0219
2 99A0675 Parts packet, screws (including):
• Top frame mounting (6)
• Base mounting (2)
• Power supply board mtg (2)
• Sensor bracket mtg (2)
• Support 1 frame mtg (2)
•Screw (2)
3 99A0219 1 Frame assembly, top with labels
4 99A0677 Parts packet, washers, (including):
• Top frame clamp (2)
• Base mounting (2)
• Motor plate mtg (4)
• Power supply board (2)
• Sensor bracket mtg (2)
5 99A0719 1 Clamp, top frame mounting
6 99A0676 Parts packet, nuts, (including):
• Base mounting (2)
• 2-56 switch mounting (2)
• Power supply cover (2)
• Power supply ground (2)
7 99A0663 1 Pulley, idler
8 99A0664 1 Belt, drive
9 99A1807 1 Cable, AC internal wiring
10 99A0653 1 Switch, lower limit microswitch
11 99A1808 1 Cord, AC external jumper
12 99A0714 1 Cover, power supply
13 99A0667 1 Power supply board
14 99A0715 1 Cable, low voltage power supply
15 99A0698 2 Clamp, feed frame
16 99A0685 1 Bushing
17 99A0654 1 Switch, paper low
18 99A0651 1 Sensor assembly, paper out/upper limit
19 99A0659 1 Frame, printer support 1
20 99A0695 1 Parts kit, paper size switch assembly
