Parts catalog 7-73
4060-xxx
Assembly 32: High-capacity feeder 5
Asm-
index
Part
number
Units Description
32—1 99A0263 3 Parts packet, screw
(auto comp assembly mounting)
2 99A1055 1 Arm assembly, pick 2000
3 99A0070 2 Roll assembly, pick
4 99A0692 1 Base, 2000 option
5 99A0263 1 Parts packet, screw (deflector mounting)
6 99A0678 1 Deflector, base
7 99A0288 1 Sensor, pass thru
8 99A1812 1 Label, tray option number
9 99A1666 1 Label, options
10 99A0677 4 Parts packet, washer
(bracket 250-sheet frame retention mounting)
11 99A0263 4 Parts packet, screw
(bracket 250-sheet frame retention mounting)
12 99A0679 2 Bracket, 250-sheet frame retention
NS 99A0717 1 Cable, paper low switch
NS 99A0720 1 Cable, lower limit switch
