Parts catalog 7-75
4060-xxx
Assembly 33: Kiosk—vertical paper adapter
Asm-
index
Part
number
Units Description
33—1 99A0231 1 Bail, support
2 99A1646 1 Arm assembly, pivot
3 99A1819 1 Mounting, frame assembly
4 99A0240 12 Parts packet, retainer
5 99A0234 16 Parts packet, screw
6 99A1705 1 Gear, idler
7 99A1704 2 Gear, idler
8 99A0197 1 Shaft, drive rear
9 99A0079 1 Tray assembly, backup roller
10 99A0208 3 Parts packet, pulley
11 99A0087 6 Spring, backup roller
12 99A0086 6 Roller, backup
13 99A1706 1 Tray assembly, drive roller
14 99A0125 1 Frame assembly, right side
15 99A0232 1 Cover, right
16 99A1820 2 Belt, 185G
17 99A0226 1 Guide, paper exit
18 99A0122 2 Shaft assembly, drive roller
19 99A0137 1 Frame assembly, left side
20 99A0088 1 Cover, backup tray
21 99A0085 1 Tray, backup roller
