Parts catalog 7-79
4060-xxx
Assembly 35: StapleSmart finisher 1
Asm-
index
Part
number
Units Description
35—1 99A2505 1 Cover, top assembly
2 99A2510 1 Clip, brush ground
3 99A2506 1 Top cover bail/plate, right side
4 99A2512 1 Door, rear access
5 99A1785 2 Latch, rear access door
6 99A2501 1 Cover, right base assembly
7 99A2503 1 Cover, stapler access
8 99A2502 1 Switch, stapler access door assembly
9 2 Screws, switch (stapled access) mounting 99A2509 Parts Packet
10 99A2519 1 Cover, accumulator assembly
11 99A2520 1 Tray, output assembly
11 99A2542 1 Tray, output
12 99A1666 1 Label, tray options
13 99A2521 1 Sensor, stapler bin empty
14 99A2541 1 Sensor cover, stapler bin empty
15 99A2511 1 Bail, center stapler
16 99A2508 1 Kit, stacking bail
17 99A2500 1 Cover, left base assembly
18 99A2507 1 Top cover bail/plate, left side
