2-72 Service Manual
4062
28x.46
x = bin
number
Paddle home position
jam
Applies to:
StapleSmart finisher
The sensor (paddle HP) does
not detect that the paddle is
operating.
1. Check all the connections on
the output option controller
card.
2. Check the sensor (paddle
HP) for damage and replace if
needed.
Go to “SFP stapler assembly
sensor (paddle HP) removal”
on page 4-132.
3. Replace the output option if
problem remains.
28x.47
x = bin
number
Paddle home position
jam
Applies to:
StapleSmart finisher
The sensor (paddle HP) does
not detect the home position
upon completion of normal
paddle operation.
1. Check all the connections on
the output option controller
card.
2. Check the sensor (paddle
HP) for damage and replace if
needed.
Go to “SFP stapler assembly
sensor (paddle HP) removal”
on page 4-132.
3. Replace the output option if
problem remains.
28x.48
x = bin
number
Deflector gate
transition to output
option not detected
Applies to:
StapleSmart finisher
The sensor (deflector gate HP)
does not detect transition of the
deflector gate to the output
option.
1. Check all the connections on
the output option controller
card.
2. Check the sensor (deflector
HP) for damage and replace if
needed.
Go to “SFP stapler assembly
sensor (deflector HP)
removal” on page 4-137.
3. Replace the output option if
problem remains.
28x.49
x = bin
number
Deflector gate
transition to standard
bin not detected
Applies to:
StapleSmart finisher
The sensor (deflector gate HP)
does not detect transition of the
deflector gate to the standard
bin.
1. Check all the connections on
the output option controller
card.
2. Check the sensor (deflector
HP) for damage and replace if
needed.
Go to “SFP stapler assembly
sensor (deflector HP)
removal” on page 4-137.
3. Replace the output option if
problem remains.
