Diagnostic information 2-73
4062
28x.50
x = bin
number
Left tamper home
position jam
Applies to:
StapleSmart finisher
The left tamper home position
is not detected by the sensor
(left tamper HP)
1. Check all the connections on
the output option controller
card.
2. Check the tamper drive belt
for damage and replace if
needed.
3. Replace the left tamper
motor assembly.
Go to “SFP stapler assembly
tamper drive motor
assembly removal” on
page 4-126.
4. Replace the sensor (tamper
HP).
Go to “SFP stapler assembly
sensor (tamper HP left and
right) removal” on
page 4-134.
4. Replace the output option if
problem remains.
28x.51
x = bin
number
Right tamper home
position jam
Applies to:
StapleSmart finisher
The right tamper home position
is not detected by the sensor
(right tamper HP)
1. Check all the connections on
the output option controller
card.
2. Check the tamper drive belt
for damage and replace if
needed.
3. Replace the right tamper
motor assembly.
Go to “SFP stapler assembly
tamper drive motor
assembly removal” on
page 4-126.
4. Replace the sensor (tamper
HP).
Go to “SFP stapler assembly
sensor (tamper HP left and
right) removal” on
page 4-134.
4. Replace the output option if
problem remains.
28x.52
x = bin
number
Paddle control motor
timer error
Applies to:
StapleSmart finisher
A software failure has occurred
with the output option.
1. Turn the machine off/on.
2. Replace the output option if
problem remains.
28x.53
x = bin
number
Eject motor encoder
not detected
Applies to:
StapleSmart finisher
The eject motor encoder is not
detected upon startup
1. Check all the connections on
the output option controller
card.
2. Replace the output option if
problem remains.
Error
code or
message
Error contents Description/Action Possible repair actions
