4 Align the fuser unit using the handles on each side, and then place it back into the printer.
1
2
2
3 Close door A.
4 If necessary, touch Continue from the printer control panel.
Paper jam in cover F (paper transport)
1 Open cover F.
2 Firmly grasp the jammed paper on each side, and then gently pull it out.
Note: Make sure all paper fragments are removed.
Note: If the paper jam on the right is difficult to remove, then rotate the knob counterclockwise.
Clearing jams
273
