Actuator with relative positioning - Dual Hall
Connection diagram:
Fig. 3 : 36xxxxx0H/1Hxxxxxx
36xxxxxxxH00xx-xxxxxxxxxxxxxxx
BROWN
BLUE
YELLOW
GREEN
RED
BLACK
+
-
