When ordering standard stroke length with endstop
1, 2, 3 or 4 the stroke length will be up to 4 mm shorter.
IC Feedback
Bus (LINbus; CAN bus or Modbus)
Single Hall
Analogue feedback 0-10V
Analogue feedback 0.5-4.5V
Analogue 4-20mA
PWM 10-90%
PWM 20-80%
IC Basic
IC
Gross
TYPE
36
=
LA36
SPINDLE TYPE
2
=
8mm
3
=
12mm
5
=
20mm
A
=
8mm + magnet for adjustable reed switch
C
=
12mm + magnet for adjustable reedswitch
E
=
20mm + magnet for adjustable reed switch
GEAR BOX
A
=
Gear rao 1:18 / 2600N or 1700N
B
=
Gear rao 1:31 / 4500N
C
=
Gear rao 1:46 / 6800N or 10000N
F
=
Gear rao 1:7 / 500N
BACK FIXTURE
0
=
=
=
=
=
=
=
=
=
=
=
=
=
M20 x 1 female adapter
1
12,9 mm hole (for 1/2" pin)
2
12,9 mm hole turned 90° (for 1/2" pin)
3
12,2 mm hole (for 12mm pin)
4
12,2 mm hole turned 90° (for 12mm pin)
5
M12 x 1,75 male adapter
6
M16 x 1,5 male adapter
7
12,2 mm hole with slot (like LA34)
8
12,2 mm hole with slot (like LA34) - turned 90°
A
12,2 mm hole with slot - AISI 304
B
12,2 mm hole with slot turned 90° in AISI 304
C
12,9 mm hole with slot - AISI 304
D
12,9 mm hole with slot turned 90° - AISI 304
PISTON ROD EYE
0
=
M20 x 1 female adapter
1
=
12,9 mm hole (for 1/2" pin)
2
=
12,2 mm hole (for 12mm pin)
3
=
M12 x 1,75 male adapter
4
=
M16x1,5 male adapter
5
=
12,2 mm hole with slot (like LA34)
A
=
12,2 mm hole with slot - AISI 304
B
=
12,9 mm hole with slot - AISI 304
C
=
Ball eye Ø12,2
D
=
Ball eye Ø16
SAFETY NUT
+
=
Standard
S
=
With safety nut
END STOP
0
=
No limit switch
1
=
Limit switch
2
=
Limit switch and EOS
7
=
8
=
IC Advanced
9
=
IC Parallel
A
=
MODBUS
B
=
LINBUS
C
=
CAN bus (J1939)
FEEDBACK
0
=
Standard (No feedback)
B
=
Analogue feedback 0-10V
C
=
Analogue feedback 0.5-4.5V
H
=
Dual Hall
K
=
Single Hall
P
=
Potenometer
5
=
PWM 10-90%
6
=
PWM 20-80%
D
=
1
=
2
=
3
=
4
=
5
=
6
=
STROKE LENGTH
100
=
100mm
150 150mm
200 200mm
250 250mm
300 300mm
350 350mm
400 400mm
450 450mm
500 500mm
550 550mm
600 600mm
650 650mm
700 700mm
750 750mm
800 800mm
850 850mm
900 900mm
950
=
=
=
=
=
=
=
=
=
=
=
=
=
=
=
=
=
950mm
999
=
999mm
MOTOR TYPE
A
=
12 VDC
B
=
24 VDC
C
=
36 VDC
1
=
12 VDC without clutch
2
=
24 VDC without clutch
3
=
36 VDC without clutch
IP DEGREE
2
=
=
IP66 Dynamic / IP69k Stac
8 IECEx / ATEX cer�fied
9
=
Harsh environment housing (IP66/IP69k)
CABLES
0
=
No cable
1
=
1,5m cable (0367046-1500)
2
=
5 m cable (0367046-5000)
3
=
0,2 m power cable with AMP connector (0367006)
4
=
1,5 m power cable +1,5m signal cable
5
=
5 m power cable + 5 m signal cable
6
=
Y-cable power and signal cable in one (0367020)
7
=
5 m powercable & datacable M12x1 (Bus)
1
2.5 mm pitch
N.A.
N.A.
10.000 N
N.A.
8 mm pitch
N.A.
N.A.
10.000 N
N.A.
12 mm pitch
2.600 N
4.500 N
6.800 N
N.A.
16 mm pitch
1950 N
3375 N
5100 N
N.A.
20 mm pitch
1.700 N
N.A.
N.A.
500 N
Ordering example
LA36
