Page 45 of 96
© 2020 LINAK A/S
IC options overview
Control
12V, 24V supply √ √ √ √ √
Basic Advanced Parallel LIN bus CAN bus
H-bridge √ √ √ √ √
Manual drive in/out √ √ √ √ √
EOS in/out - √ √ √ -
Soft start/stop √ √ √ √ √
Feedback
Voltage √ √ * - - -
Current - √ ** - - -
Single Hall √ √ - - -
PWM - √ - - -
Custom feedback type - √ - - -
Monitoring
Temperature monitoring √ √ √ √ √
Current cut-off √ √ √ √ √
Ready signal - - - - -
BusLink
Service counter - √ √ √ √
Custom soft start/stop - √ *** √ *** √ *** √ ***
Custom current limit - √ √ √ √ √
Speed setting - √ √ √ √
Virtual end stop - √ √ √ √
* Configure any high/low combination between 0 - 10V
*** Configure any value between 0 - 30s
** Configure any high/low combination between 4 - 20mA
Position (mm) - - - √ √
