Feedback configurations available for IC Basic, IC Advanced and Parallel
Pre-configured Customised
range
Pros Cons
None N/A N/A
PWM
Feedback
10 – 90 %
75 Hz
0 – 100 %
75 – 150 Hz
Suitable for long
distance transmission.
Effectual immunity to
electrical noise.
More complex
processing required,
compared to AFV and
AFC.
Single Hall* N/A N/A Suitable for long
distance transmission.
No position indication.
Analogue
Feedback
Voltage
(AFV)*
0 - 10V Any
combination,
going negative
or positive.
E.g. 8.5 – 2.2V
over a full
stroke.
High resolution.
Traditional type of
feedback suitable for
most PLCs.
Easy faultfinding.
Independent on stroke
length, compared to a
traditional mechanical
potentiometer.
Not recommended
for applications with
long distance cables or
environments exposed
to electrical noise.
Analogue
Feedback
Current (AFC)
4 - 20mA Any
combination,
going negative
or positive.
E.g. 5.5 – 18mA
over a full
stroke.
High resolution. Better
immunity to long cables
and differences in
potentials than AFV.
Provides inherent error
condition detection.
Independent on stroke
length, compared to a
traditional mechanical
potentiometer.
Not suitable for signal
isolation. Only to be
used on differential
input card. Do not use
single ended input
card.
Do NOT connect or
put the white wire
anywhere near GND, as
this will create ground
loops, disturbing the
mA-signal.
Endstop signal
in/out**
At physical end
stops.
Default for IC
Advanced.
Any position.
(Not IC Basic)
Can be set at any
position over the full
stroke length.
(Not IC Basic)
Only one endstop can
be customised.
(Not IC Basic)
All feedback configurations are available for IC Advanced.
* IC Basic feedback configurations available: EOS
** Parallel feedback configurations available: EOS
