Actuator with relative positioning - Single Hall
Connection diagram:
Fig. 5 : 36xxxxx0K/1Kxxxxxx
36xxxxxxxK00xx-xxxxxxxxxxxxxxx
BROWN
BLUE
RED
VIOLET
BLACK
+
-
