Specifications
Motor: Permanent magnet motor 12, 24, or 36V *
Cable: Motor: 2 x 14 AWG PVC cable
Control: 6 x 20 AWG PVC cable **
Gear ratio: 6 different gear ratios available in steel
(500 N, 1,700/2,600 N, 4,500 N, and 6,800/10,000 N)
Slip clutch: Mechanical overload protection through an integrated slip clutch
Brake: Integrated brake ensures a high self-locking ability. The brake is deactivated when
the actuator is powered to obtain a high efficiency
Hand crank: As a standard feature the actuator can be operated manually
Housing: The housing is made of casted aluminium, coated for outdoor use and in harsh
conditions
Spindle part: Outer tube: Extruded aluminium anodised
Inner tube: Stainless steel AISI304/SS2333
Acme spindle: Trapezoidal spindle with high efficiency
Temperature range: - 30
o
C to +65
o
C For IECEx/ATEX: - 25
o
C to +65
o
C
- 22
o
F to +149
o
F - 13
o
F to +149
o
F
Full performance +5
o
C to +40
o
C
End play: 2 mm maximum
Weather protection: Rated IP66 for outdoor use. Furthermore, the actuator can be washed down with a
high-pressure cleaner (IP69K)
Usage:
• Duty cycle at 600mm stroke is max. 20% (4 min. drive and 16 min. rest)
Duty cycle at 601-999mm stroke is max. 15% (3 min. drive and 17 min. rest)
Duty cycle at 10,000 N is max. 5%
• Storage temperature: -55
o
C to +105
o
C
• Noise level: 73 dB (A) measuring method DS/EN ISO 3743-1 actuator not loaded
• Safety device regarding functional failure:
Safety nut
The LA36 has a built-in safety nut in push as an option. Actuators with safety nut in push can only function
when used in push applications. The safety nut comes into operation should the main nut fail. Afterwards it is
only possible to drive the actuator into the innermost position. Thereafter, the actuator will not function any
more and must be sent for service
Mechanical endstop
LA36 is equipped with mechanical endstop
* Modbus actuators only 24V - please see the Modbus installation guide:
http://www.linak.com/techline/?id3=2363
** Special control cabels for the Modbus actuator - please see the Modbus installation guide:
http://www.linak.com/techline/?id3=2363
