Actuator with absolute positioning - PWM
Connection diagram:
Fig. 11 : 36xxxxx15/16xxxxxx
36xxxxxxxF00xx-xxxxxxxxxxxxxxx
BROWN
BLUE
PWM
RED
VIOLET
+
BLACK
-
