Page 79 of 96
© 2020 LINAK A/S
*
LA36
Ordering example Econ
IC options: IC LINbus Modbus Parallel
LA36 actuator:
� � � �
36 120 000 A Z 23 B A - 6 1 6 G 3 0300 B C S 0 0 0
Type: 36 = LA36
Spindle type: 080 = 8 mm
120 = 12 mm
160 = 16 mm
200 = 20 mm
Stroke length: XXX = mm (In steps of 5 mm)
Axx = 10xx mm
Bxx = 11xx mm Stroke > 999 mm
C
00
= 1200 mm
Safety nut: 0 = None
A = Safety nut
Feedback: 0 = None
A = Hall Potentiometer
F = PWM
H = Dual Hall
L = Potential free end stop signals
P = Potentiometer (Only with the platform: Standard)
Z = Hall and potentiometer
X = Special
Platform: 00 = None (P0) 13 = IC Basic
23 = IC Advanced 33 = IC Parallel
43 = IC Parallel with feedback 53 = IC GPO
63 = IC Selflearning stroke 04 = MODbus
06 = LINbus Switch 16 = LINbus Zero point
07 = CANbus Switch 17 = CANbus Zero point
XX = Special
Motor type: A = 12 VDC Normal 1 = 12 VDC With dummy clutch
B = 24 VDC Normal 2 = 24 VDC With dummy clutch
C = 36 VDC Normal 3 = 36 VDC With dummy clutch
J = 48 VDC Normal 4 = 48 VDC With dummy clutch
X = Other
IP degree / A = IP66
Housing 4 = IP66 UL508 approved reinforced house 5 = IP66 UL508 approved
6 = IP66 Reinforced house 8 = IP66 ATEX / IECEx approved
9 = Harsh environment*
Reed - = Without magnet for a customer-mounted Reed limit switch
+ = With magnet for a customer-mounted Reed limit switch
Colour 6 = Dark Olivish gray NCS S7000-N*
X = Special
Back fixture: 1 = 0 degrees 3 = Ball eye
2 = 90 degrees 4 = Outer thread
A = 30 degrees 5 = Inner thread
B = 60 degrees 6 = Rotated (30° Interval)
C = 120 degrees
X = Special
D = 150 degrees
Piston rod eye: 1 = With slot 5 = inner thread
2 = Solid 6 = Ball eye
4 = Outer thread X = Special
}
Option Position: E = Gear ratio 1:7 (F-gear) F = Gear ratio 1:18 (A-gear)
G = Gear ratio 1:31 (B-gear) H = Gear ratio 1:46 (C-gear)
Brake: 1 = Push 2 = Pull
3 = Push / Pull
Install. diam.: 0300 = mm (min length)
XXXX = mm
End stop signal: A = A_HIGH / A_HIGH B = A_LOW / A_HIGH
(EOS in/EOS out) C = A_HIGH / A_LOW D = A_LOW / A_LOW
E = LOW / A_HIGH F = HIGH / A_HIGH
G = LOW / A_LOW H = HIGH / A_LOW
J = A_HIGH / LOW K = A_LOW / LOW
L = A_HIGH / HIGH M = A_LOW / HIGH
N = LOW / LOW O = HIGH / LOW
P = LOW / HIGH Q = LOW / HIGH
X = Special **
Plug type: 0 = None. - Is to be chosen, if cable and connectors is not wanted
7 = AMP super seal - Moulded
9 = Deutsch - Moulded
C = Flying leads. - Chose this, if a connector is not wanted
H = AMP
J = Deutsch (DT4)
K = AMP super seal
U = Power cable UL1203 US
X = Special
Cable: 0 = None. A = 90° Angled connector
S = Straight Y = Y-Cable
X = Special
Parallel mode: 0 = Non critical Parallel 2-8 = critical parallel (count of actuators)
SW Config: 0 = Standard X = Special Configuration
Not used: 0
** A_High is active high and A_LOW is active low. HIGH is constant high and LOW is constant low.
* With Harsh environment the housing is Black
