Actuator with absolute positioning - Mechanical potentiometer feedback
Connection diagram:
Fig. 9 : 36xxxxx0P/1Pxxxxxx
36xxxxxxxP00xx-xxxxxxxxxxxxxxx
BROWN
BLUE
WHITE (VCC+ to POT)
VIOLET
BLACK
+
-
