BusLink service counter - Reason for last stop
For more information and easy set-up of BusLink, please follow this link to view the Quick Guide for
BusLink: http://www.linak.com/techline/?id3=2356
Initialisation procedure:
To initialise the actuator(s), move each actuator into fully extended and fully retracted position.
Either initialise the actuators one at a time through BusLink, or use the Parallel manual service mode
(see page 56).
In case the initialisation does not solve the issue, please contact your local LINAK supplier
Possible cause Action/Info
H-bridge error
Internal SMPS error
• Please contact your local LINAK supplier for further
instructions
Overcurrent • The actuator(s) cannot continue in the same direction
• Reactivation is needed in the opposite direction
EOS error • Please contact your local LINAK supplier
Hall error • The actuator(s) stop. When seeing hall error, the actuator
goes into ‘position lost’, and the whole system will need
initialisation
Find more info on the initialisation procedure below
Out of range temperature for ambient location
Out of range temperature at FET location
The above can be due to high environment
temperature or high duty cycle
• The error causes the actuator(s) to stop. After elimination of
the error (cooling down) and reactivation of the movement,
the actuator(s) will move normally
• This may not be used for stopping the actuator(s)
Overvoltage • When detecting overvoltage, the actuator(s) stop. The
actuator(s) remain stopped until the error condition is
removed. To remove the error condition, the voltage level
must be below 38V and the Run In/Run Out signals must be
removed before the next movement
Undervoltage • When detecting undervoltage, the actuator(s) stop. The
actuator(s) remain stopped until the error condition is
removed. To remove the error condition, the voltage level
must be above 8V and the Run In/Run Out signals must be
removed before the next movement
