Actuator with IC Basic
I/O specifications:
Input/Output Specification Comments
Violet Analogue feedback
0-10V (Option 7.2)
Standby power consumption:
12V, 60mA
24V, 45 mA
Ripple max. 200mV
Transaction delay 20ms
Linear feedback 0.5%
Max. current output: 1mA
It is recommendable to have the actua-
tor to activate its limit switches on a
regular basis, to ensure more precise
positioning
Single Hall output (PNP) (Option 7.1)
Movement per Single Hall pulse:
LA362C: Actuator = 0.1 mm per count
LA363C: Actuator = 0.2 mm per count
LA363B: Actuator = 0.3 mm per count
LA363A: Actuator = 0.4 mm per count
LA365A: Actuator = 0.7 mm per count
Frequency:
Frequency is 30-125 Hz on Single Hall
output depending on load and spindle.
Overvoltage on the motor can result in
shorter pulses
Output voltage min. V
IN
- 2V
Max. current output: 12mA
Max. 680nF
White Signal GND For correct wiring of power GND and
Signal GND see page 45
It is recommended that the actuator activates its limit switches on a regular basis, to ensure more precise
positioning. The actuator can also go into the position lost state. When the actuator goes in position lost state,
the feedback level will remain the highest level until the actuator is initiated. For instance, if feedback is 0-10 V,
the feedback level will remain 10V until the actuator is initialised. Both physical end stop switches need to be
activated for correct initialisation of the feedback. There is no rule as to which one needs to be activated first.
