Lonza 4D-Nucleofector - LV Unit (Scalable Volume): Loading Samples

28 | 4D-Nucleofector
®
Manual
G
H
A
B
C
D E
F
G
H
I
Figure 2.37: Mounting the 4D-Nucleofector
®
LV Nucleocuvette
®
Catridge.
(A) LV Catridge inseted into slot and venting tube attached.
(B) Setup screen for LV Catridge.
(C) Remaining time for tube insetion is shown. If the time is not sufficient,
you can stat the process again after the time ran up.
(D) Insetion into three pinch valves.
(E) Detail
(F) Insetion into the T connector holder and liquid sensors.
(G) Insetion in upper pump.
(H) Reservoir filled with medium and mounted into a 4D Nucleofector
®
LV
Reservoir Rack.
(I) Manual connection with LV Catridge.
The pictures reflect the first version of the consumables, later versions
may show slight modifications. However, the mounting procedure
stays the same.
