Basic Setup4
4. Lower the camera base onto the mounting bracket so the 2 tabs in the mounting bracket lock
into the 2 slots in the camera base.
LWB4800 / LWB4900 Series LWB5800 / LWB6800 Series
5. Insert the security screw through the fasteners on the top of the camera base and mounting
bracket to secure the camera to the mounting bracket. Tighten using the included screwdriver
(item A+B in toolkit).
LWB4800 / LWB4900 Series LWB5800 / LWB6800 Series
6. OPTIONAL: Tighten the pre-installed locking screw on the base of the Power Pack using the
included screwdriver (item A+B in toolkit).
NOTE
You will need to loosen the locking screw to remove the Power Pack in the future.
#LX400109; r. 2.0/54857/55689; en-US 13
