Replacing the Hard Drive21
The system comes with a pre-installed 3.5" SATA hard drive. You can replace the hard drive with
one up to a maximum size of 10TB.
21.1 Removing the Hard Drive
CAUTION
Make sure that the system is OFF and the power adapter is disconnected before removing/installing a hard drive.
To remove the hard drive:
1. Power off the system, and unplug all cabling from the system.
2. Turn the recorder over. Remove the bottom panel screws (6×).
#LX400113; r. 1.0/56015/56022; en-US 106
