Playback10
10.4 Video Clip Backup
Video clip backup allows you to select a duration of video during playback mode and save it to a
USB device (not included).
To use video clip backup:
1. Connect the USB thumb drive (not included) to a free USB port on the recorder.
2. From the Live View display, right-click to open the Quick Menu, then click Playback.
3. Use the calendar on the right to select the day to playback.
4. Check the channels you want to play back. Click the icons to the right of each channel name
to choose the video quality (
for Main Stream, for Sub Stream).
5. Click inside the video bar to select the playback time. The system will begin playing back vid-
eo from the selected time.
6. Click to mark the beginning of the video clip, then click again to mark the end of the
video clip.
#LX400113; r. 1.0/56015/56022; en-US 32
