Lorex NR800 Series User Manual

NR800 Series System Specifications
25
Network Protocol HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP,
SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP
Filter
Network Interface 10/100/1000Mbps, RJ-45
Network Bit Rate 256Mbs total
48~8192kbps per camera
25.8 General
Power Consumption Approx. 20 watts (No HDD Installed)
Supply Voltage 100VAC-240VAC, 50/60Hz
Total PoE Power Output (across all channels) 120W (Max 25W per Camera)
Unit Weight NR8081: 2.93kg / 6.46lbs
NR8163: 6.62kg / 14.59lbs
NR8326: 7.24kg / 15.96lbs
Dimensions (W x H x D) NR8081: 375mm x 285mm x 55mm / 14.7” x
11.2” x 2.1”
NR8163 / NR8326: 440mm x 410mm x 70mm /
17.3” x 16.1” x 2.8”
Operating Temperature 14° ~ 131° F / –10° ~ 55° C
Humidity 10 ~ 90% RH
25.9 Recording Resolution (Pixels) & Speed (FPS — Frames per second)
Model FPS
720P
1280x720
1080P
1920x1080
8ch
Total 240 240
Per channel 30 30
16ch
Total 480 480
Per channel 30 30
32ch
Total 960 960
Per channel 30 30
As our products are subject to continuous improvement, Lorex Corporation and its sub-
sidiaries reserve the right to modify product design, specifications, and prices without no-
tice and without incurring any obligation. E&OE
#LX400021; r. 4.0/30344/30494; en-US
166
