Lorex NR800 Series User Manual

NR800 Series System
Specifications
25
25.1 System
Operating System
Embedded LINUX
Pentaplex
Simultaneous View, Record, Playback, Backup,
and Remote Monitoring
Number of Channels 8/16/32 Channels
25.2 Inputs/Outputs
Video IN 8 ch: 8 PoE Video Input
16/32 ch: 16 PoE Video Input
Video OUT
No
VGA OUT Yes
HDMI Yes
Audio IN
1 Line IN (RCA)
Audio OUT 1 Line OUT (RCA)
USB Port 1 at the back, 1 at the front
Alarm IN 8 ch: 8 Alarm IN
16/32 ch: 16 Alarm IN
Alarm OUT 8 ch: 3 Alarm OUT
16/32 ch: 4 Alarm OUT
Video Output Resolution
1920×1080, 1280×1024, 1280×720, 1024×768
PTZ Control
Lorex IP PTZ cameras only
25.3 Display
Display Split 8 ch: 1/4/8/9
16/32 ch: 1/4/8/9/16
Live Display Speed 8 ch: 240FPS NTSC, 200 PAL
16 ch: 480FPS NTSC, 400 PAL
OSD Camera Title, Time, Camera Lock, Motion Detec-
tion, Recording Status
System Navigation USB mouse, IR remote control, front panel
buttons
Motion Area Setting Adjustable grid (22x18)
Sensitivity Levels
100
Firmware Upgrade
Automatic over the Internet & via USB device and
network
User Authority By user group
Time Synchronization
Auto time sync by NTP server
25.4 Recording
Compression H.264
Resolution 1MP 720P (1280×720)
2MP 1080P (1920×1080)
3MP 1080P (2048 x 1536)
4MP 1080P (2864 x 1632)
#LX400021; r. 4.0/30344/30494; en-US
164
