Lorex NR800 Series User Manual

Recording Audio23
Option B: Connect a camera with audio input.
NOTE
The microphone must have its own power source.
23.2 Step 2 of 2: Configuring audio recording
1. Right-click and click Main Menu. Enter the system user name (default: admin) and
password (default: 000000) if prompted.
2. Click
and select Recording>Recording.
3. Under Channel, select the channel where the audio-capable camera is connected.
4. Under Audio/Video, check the box on the left to enable audio recording.
5. Under Audio Encode, select the format that will be used to record audio. G711a is
recommended.
6. Click OK to save changes.
#LX400021; r. 4.0/30344/30494; en-US
161
