Lutz BE10 - Calibration with a Comparative Measurement in Volume Preset

36
0698-651 Operating unit - 04/2021
en
In this screen, enter the value read from the vessel.
Press "←← C" to delete the last entry on the display.
Use "0 to 9” and "."toenterthellvolume.
Press "Cncl" to cancel the entry and return to the previous screen.
Press "OK"tosavethedisplayedvolumeandnishmakingentries.
You can enter an 8-digit comment about the calibration factor in this display.
Press "
←← C" to delete the last entry on the display.
Use "A-Z, 0...-9, and .,/_" for special chars to enter the comment. If
necessary, press the same button several times until the required character
appears.
Press " " to enter a space into the comment.
Press "Cncl" to cancel the entry and return to the previous screen.
Press "OK"tosavethedisplayedcommentandnishmakingentries.
9.7.2 Calibration with a comparative measurement
in volume preset
RM
Menu
?
OK
MAN
Cal. process
?
?
OK
Continue
Filling process
complete?
Cal. process
OK
On the next
screen, enter
the value read
from the
vessel.
Value on vessel
Value on vessel
?
?
OK
Cncl
←←
C1
2 3
654
7
8 9
0
Comments
?
?
OK
Cncl
←←
C
.,/_
ABC DEF
MNOJKL
GHI
PQRS
TUV WXYZ
0...9
1.2345
Station1
Current setting
Operating mode
Display options
Calibrate
Total volume
Menu 1/5
?
?
Calibrate
?
?
Cancel
Comparative
measurement
Manual
input
Cal. process
?
?
OK
Cancel
On the next
screen, press
"START" to
fill the vessel.
Press "STOP"
when the
required
Menu
?
?
AUTO
START
Change
volume
