Lynx NGT-9000s
Installation Manual
Table 1-4: Specifications for Detachable configuration module
PART NUMBER:
9230-17003-01
CERTIFICATION:
USA (FAA): TSO-C145c, C154c, C157a, C195a.
See paragraph 1.7 for specific TSO information.
Listed are current authorizations at time of publication, contact Field Service Engineering for
latest certification information
RTCA COMPLIANCE:
The DCM is tested as part of the NGT-9000.
WEIGHT:
Negligible
SIZE:
Length: 6 inches (includes wires)
POWER REQUIREMENTS:
3.3 Vdc (regulated via J1 connector)
INTERFACE (S):
I
2
C serial interface
OPERATING TEMPERATURE:
-40° to +70°C (-40° to +158°F)
STORAGE TEMPERATURE:
-55° to +85°C (-67° to +185°F)
MAXIMUM ALTITUDE:
55,000 ft (installation environment)
SCHEDULED MAINTENENACE:
None.
SERVICE LIFE: Unlimited.
REPAIRABILITY:
Replacement only.
Page 1-14 General Information 0040-17001-01
January 15, 2015 Revision A
