MacDon DWA - Page 101

215626 91 Revision A
Ref Part Number Description Qty Serial Number
29 50104
FITTING – ELBOW 90° HYDRAULIC
1
30 135266 FASTENER – CABLE TIE, LIGHT BLUE
1
A
30441 WASHER – HARDENED 3
B
145249
BOLT – HEX HEAD, 5/8 NF x 1.0 LG GR 5 ZP
3
C
172259
BOLT – SHOULDER, 3/8-16 UNC
4
D
18709
SETSCREW – HEXHD, SKT CUP PT 3/8 NC x 5/8 LG
2
E
18664
NUT – HEX JAM, 3/8-16 UNC GR 5 ZP
2
F
145249
BOLT – HEX HEAD, 5/8 NF x 1.0 LG GR 5 ZP
3
G 30441 WASHER – HARDENED 3
H
18598
WASHER – SAE FLAT, 13/32 ID x 13/16 INCH OD ZP
2
J
19966
BOLT – RDH, SQ NECK, 3/8 NC x 1.25 LG GR 5 ZP
1
K
50186
NUT – FLG, LOCK, SMTH FACE, DT, 1/2-13 UNC – GR 5
7
L
21471
BOLT – RHSN, 1/2 NC x 1.25 GR 5 ZP
1
M
18590
NUT – HEX, 3/8-16 UNC GR 5 ZP
4
N
11695 WASHER – FLAT 3
P
30228
NUT – FLG, DT, SMOOTH FACE, 3/8-16 UNC
15
Q 21066
BOLT – RHSN, 1/2 NC x 1 GR 5 ZP
1
R
135157 SCREW – MACHINE 14
S 18593
NUT –
HEX, 3/4-10 UNC GR 5 ZP
2
T
18689
NUT – HEX, LOCK, DISTORTED THREAD, 3/4-10 UNC
2
REPAIR PARTS
