5.5 Hydraulics and In-Cab Electrical
This section details the hydraulic and in-cab electrical parts and hardware needed to install the Double Windrow
Attachment (DWA) on an M series windrower.
Figure 5.7: Hydraulics and In-Cab Electrical
$
%
&
'
(
)
*
+
-
A - M150/M200 A Series Or R Series: Case Drain B - M150/M200 A Series With Reverser: Case Drain
C - M150/M200 D Series: Case Drain D - M150/M200 D Series With Reverser: Case Drain
E - M155/M155E4/M205: Case Drain F - In-Cab Electrical
G - M150/M200 Shown (5 Series Similar) H - Optional M200 Only
J - Optional M155/M155E4/M205
REPAIR PARTS
To Next Page
