MacDon DWA - Decal and Reflector Locations

215626 107 Revision A
Ref Part Number DESCRIPTION Qty Serial Number
1
176767 DECAL – HEADER POSITION, HORIZONTAL FORMAT 3
2 176768 DECAL – HEADER POSITION, VERTICAL FORMAT
1
3 115146 REFLECTOR – AMBER
1
115145
REFLECTOR – FLUORESCENT RED-ORANGE
1
115147
REFLECTOR – RED
1
4
220084 DECAL – DRAPER TENSION
1
5
174683 DECAL – WARNING DWA LINKAGE PINCH POINT, 2 PANEL 2
6 166466
DECAL – WARNING, HIGH PRESSURE HYDRAULICS, 2 PANEL
1
7
176295 DECAL – DECK LIFT LOCK 1
5.7.1 Decal and Reflector Locations
Ensure that replacement decals are installed in the proper location on a Double Windrow Attachment (DWA) on an M
series windrower.

$
%
&
'
(
)
Figure 5.12: Decal and Reflector Locations
A - MD #176071 – Header Position, Horizontal B - MD #220084 – Draper Tension C - MD #174683 – DWA Linkage Pinch Point
D- MD #176295 – Deck Lift Lock E - MD #115146 – Reflector, Amber F - MD #166466 – High Pressure Hydraulics
REPAIR PARTS
