MacDon DWA - Page 118

215626 108 Revision A

$
%
&
'
$
(
Figure 5.13: Decal and Reflector Locations
A - MD #176071 – Header Position, Horizontal B - MD #176072 – Header Position, Vertical C - MD #174683 – DWA Linkage Pinch Point
D- MD #115147 – Reflector, Red E - MD #115145 – Reflector, Fluorescent Red-Orange
REPAIR PARTS
