MacDon DWA - 3.4 Setting Draper Speed

215626 61 Revision A
3.4 Setting Draper Speed
The draper speed is controlled by the draper speed control knob on the combine console.

$
%
&
Figure 3.6: DWA Controls
A - Draper Speed Knob B - DWA Down Rocker Switch
C - DWA Up Rocker Switch
To set the draper speed, turn draper speed control knob (A) on
the console; the knob may not be exactly as shown.
OPERATION
