5.6 Hydraulic Service Components
This section details the parts which can be used to repair the hydraulic system on a Double Windrow Attachment (DWA) on
an M series windrower.
Figure 5.9: Hydraulic Service Components

$
%




A - Eaton MCD-8286, Serial No. 207009 and Below B - Eaton 630AA00821A, Serial No. 207010 and Above
REPAIR PARTS
