MacDon DWA - Page 109

215626 99 Revision A
Ref Part Number Description Qty Serial Number
1
139508 MANIFOLD – DWA DRIVE, SEE NEXT PAGE FOR SERVICE PARTS
1
2 139974 VALVE BLOCK AUX LIFT, SEE NEXT PAGE FOR SERVICE PARTS
7
1
3 144807 HOSE – HYDRAULIC
1
4
21843
FITTING – ELBOW 90° HYDRAULIC
1
5
50221
FITTING – ELBOW 90° HYDRAULIC
2
6 50102 FITTING – HYDRAULIC TEE 2
7
21830 FITTING – HYDRAULIC CONNECTOR
1
8 30695 FITTING – HYDRAULIC CONNECTOR 2
9 30282
FITTING – ELBOW 90° HYDRAULIC
2
10 30556
FITTING – ELBOW 90° HYDRAULIC
1
11
118084 FTG – HYDRAULIC REDUCER
1
12 30994 PLUG – HEX CW O-RING 2
13 132867 HOSE – HYDRAULIC 2
14
176077 HOSE – HYDRAULIC
1
15
50104
FITTING – ELBOW 90° HYDRAULIC
1
16 144805 HOSE – HYDRAULIC
1
17
144806 HOSE – HYDRAULIC
1
18 21805 FITTING – ELBOW HYDRAULIC
1
19
REF
MOTOR – SEE DRAPER AND DECK
20
REF
CYLINDER – SEE DECK SUPPORTS AND LINKAGE
21 109575 SWITCH – ROCKER, MOM-OFF-MOM
1
22 109718 GAUGE – POTENTIOMETER
1
23 138691 KNOB – SPEED CONTROL
1
24 21821
BOLT – HH FLG (SERR FACE) 3/8 NC x 0.75 GR 5 ZP
2
REPAIR PARTS
7. Refer to service bulletin SB #1210 regarding software update required.
