MacDon DWA - Page 107

215626 97 Revision A
Ref Part Number Description Qty Serial Number
1 144590
SUPPORT WELDMENT KIT, CONSISTS OF 176062, ITEMS 2, 6, 13 &
HARDWARE. 1
176062 SUPPORT WELDMENT 1
2
144587
SPACER – 1-1/2” OD x 1” ID x 2-3/4 ” LONG
2
3
176767 DECAL – HEADER POSITION, HORIZONTAL FORMAT 2
4 172910 SHAFT 1
5 176016 PIN – L1
6 144853 SUPPORT 1
7 176066 CYLINDER – GAS SPRING 1
8 103738 CLAMP – PVC INSULATED 13/16" TUBE SIZE 2
9 16266 PIN – SPRING, 1/4 DIA. x 1.25 LG 1
10 2147 PIN – SPRING, 1/4 DIA. x 1.5 LG 1
11 21805 FITTING – ELBOW HYDRAULIC 1
12 144806 HOSE – HYDRAULIC 1
13 176060 CHANNEL WELDMENT 1
A 176067 BOLT – HEXHD, 5/16 NC x 1-3/4 INCH TFL GR 5 ZP 2
B 35689 NUT – SPECIAL (TAPER FACING ROD END) 4
C 18589 NUT – HEX, 5/16 NC 2
D 21491 BOLT – HEX HEAD, 1/2 NC x 1.25 LG GR 5 ZP 2
E 50186 NUT – FLG LOCK, SMTH FACE, DT, 1/2-13 UNC GR 5 6
F 102266 BOLT – RHSSN, 3/4 NC x 4.5 LG GR 5 ZP 2
G 18601 WASHER – SAE FLAT, 13/16 ID x 1.5 INCH OD ZP 5
H 18593 NUT – HEX, 3/4-10 UNC GR 5 ZP 5
J 30896 BOLT – HEX HEAD, 3/4-10 UNC x 3.50 LG 1
K 30549 BOLT – HEX HEAD, 3/4 NC x 5.5 LG GR 5 ZP 1
L 21354 BOLT – HEX HEAD, 3/8 NC x 2.0 LG GR 5 ZP 1
M 30228 NUT – FLG, DT, SMOOTH FACE, 3/8-16 UNC 3
N 20535 WASHER – FLAT 2
P 21264 BOLT – HEX HEAD, 3/8 NC x 1.25 LG GR 5 ZP 2
Q 18640 WASHER – LOCK, 3/4 5
R 18599 WASHER – FLAT, 17/32 INCH I.D 4
S 21880 BOLT – HEXHD, 1/2 NC x 2.75 LONG, GR 5, ZP 4
REPAIR PARTS
