MacDon DWA - Page 103

215626 93 Revision A
Ref
Part Number
Description
Qty
Serial Number
1
172746
ARM – DECAL ASSEMBLY
1
2 174683
DECAL – WARNING DWA LINKAGE PINCH POINT, 2 PANEL
2
3 144592
ARM – FRONT WELDMENT
1
4
144593
ARM – BOTTOM WELDMENT
1
5
144594
CLEVIS – WELDMENT
1
6 172910
SHAFT
1
7
176018
SHAFT
1
8 176023
SHAFT
1
9 176748
KIT – M-SERIES DWA SWITCH
5
1
10
183856
HARNESS – DWA
1
11
208966
CYLINDER – HYDRAULIC
1
176031
SEAL KIT – FOR CYLINDER
12 172664
CLEVIS
1
13 144996
JOINT ASSEMBLY
1
14
18626
PIN – CLEVIS
1
15
18648
PIN – COTTER, 3/16 DIA. x 1.25 ZP
4
16 20312
PIN – CLEVIS
1
17
18627
PIN – CLEVIS
2
18 18671
FITTING – LUBE, 1/4-28 UNF
4
19 30282
FITTING – ELBOW 90° HYDRAULIC
1
20 144805
HOSE – HYDRAULIC
1
21 176768
DECAL – HEADER POSITION, VERTICAL FORMAT
1
22 172903
TUBE
1
23 144870
RAIL WELDMENT
1
24 139491
PLATE – HANDRAIL ADAPTER (M155/M205 ONLY)
1
176533
KIT – DWA RAIL ADAPTER
6
25 138744
HARNESS – M205, DWA EXTENSION (USE IF REQUIRED)
1
REPAIR PARTS
5. The kit includes the support (MD #176655), the switch (MD #200974), the wiring harness (MD #183856), installation
hardware, and installation instructions.
6. The kit contains the handrail support (MD #139491), cable ties (MD #209608), a nut (MD #50186), a bolt
(MD #21449), and installation instructions.
