MacDon DWA - Page 59

215626 49 Revision A

&;;;
0;;;
':$,167$//('"
12<(6
%
$
Figure 2.89: DWA Controls
4. Press SELECT (B) until DWA INSTALLED? appears on the
upper line.
• NO/YES appears on the lower line.
5. Press right arrow (A) to select YES. Press SELECT (B).

&;;;
0;;;
6:$3':$&21752/6"
12<(6
Figure 2.90: DWA Controls
6. SWAP DWA CONTROLS? appears on the upper line.
• NO/YES appears on the lower line.
NOTE:
This step swaps the DWA controls from the console switch
to the ground speed lever (GSL) reel fore-aft buttons.

&;;;
0;;;
':$$87283'2:1"
12<(6
'
&
%
$
Figure 2.91: DWA Auto Up/Down
7. Press right arrow (C) to select YES. Press SELECT (D).
• DWA AUTO UP/DOWN? appears on the upper line.
• NO/YES appears on the lower line.
NOTE:
If you select YES, the DWA Auto-Up function will be
activated by the GSL reel fore-aft button.
8. Press right arrow (C) to select YES. Press SELECT (D).
9. Press PROGRAM (A) to exit programming mode or press
SELECT (D) to proceed to the next windrower setup action.
SETUP INSTRUCTIONS
