MacDon DWA - Page 65

215626 55 Revision A

$
$
Figure 2.100: Overflow Hoses
6. Trim hose (A) to length as follows:
• R Series Rotary Disc Header: Leave approximately 180
mm (7 in.) of free hose below the windrower frame.
• A Series Auger and D Series Draper Header: Leave
approximately 360 mm (14 in.) of free hose below the
windrower frame.
SETUP INSTRUCTIONS
