Figure 4.24: Newer DWA Drive Block and Lift Block (MD #139974) Schematic
A - To Header Lift Block
1
B - DWA Lift Block
C - DWA Lift Cylinder D - DWA Draper Motor
E - DWA Drive Block F - To Manifold Cooler Bypass
G - Tank Line
23
MAINTENANCE AND SERVICING
1. The auxiliary block (MD #139974) is bolted directly to the main lift block, depending on windrower options. Ports T
and P are direct links.
2. M150/M200 to port T on knife drive block.
3. M155/M155E4/M205 direct to reservoir.
