MacDon DWA - Page 97

215626 87 Revision A
Ref Part Number Description Qty Serial Number
1 172730 DECK – COMPLETE WITH DECALS 1
2 176767 DECAL – HEADER POSITION, HORIZONTAL FORMAT 1
3
115146 REFLECTOR – AMBER 1
4
220084 DECAL – DRAPER TENSION 1
5 166466 DECAL – WARNING, HYDRAULIC, 2 PANEL 1
6 120449 MEMBER – LH STABILIZER WELDMENT 1
7 120451 BELL CRANK WELDMENT – LH 1
8 120462 MEMBER – COMPRESSION WELDMENT 1
9 145428 INDICATOR 1
10 145548 SPRING – LEAF (TENSIONER) 1
11 132531 SPACER 1
12 132532 SPACER 1
13 109791 MOULDING 2
A 19965 BOLT – RHSN, 3/8 NC x 1.0 GR 5 ZP 1
B 172259 BOLT – SHOULDER, 3/8-16 UNC 1
C 21575 BOLT – HEX HEAD, 1/2 NC x 1.0 GR 5 ZP 1
D 30441 WASHER – HARDENED 8
E 135906 BOLT – HEX HEAD, 5/8 NC x 7.5 LG TFL GR 5 ZP 1
F 20077 BOLT – HEX HEAD, 3/8 NC x 1.0 LG GR 5 ZP 1
G 21491 BOLT – HEX HEAD, 1/2 NC x 1.25 LG GR 5 ZP 1
H 137727 NUT – HEX JAM, DT, 1/2-13 UNC GR 5 ZP 2
J 18599 WASHER – SAE FLAT, 17/32 ID x 1 1/16 INCH OD ZP 1
K 42592 WASHER – FLAT 1
L 30228 NUT – FLANGE, DT, SMOOTH FACE, 3/8-16 UNC 4
M 145361 NUT – SPECIAL 1
N 14338 RIVET – BLIND 1/8 x 1/8 2
REPAIR PARTS
