MacDon DWA - Page 99

215626 89 Revision A
Ref Part Number
Description Qty Serial Number
1
144833 ROLLER – IDLER WELDMENT
1
2 176678 ROLLER – DRIVE WELDMENT
1
3 144501 ARM – SUPPORT
1
4
144499 ARM – ROLLER SUPPORT
1
5
176000 ARM – SUPPORT WELDMENT
1
6 144837 ARM – SUPPORT REAR
1
7
165735 PIN ASSEMBLY – DRAPER ROLLER 3
8 144832
MOTOR – HYDRAULIC M & S 1.52 CI
1
132759
SEAL KIT – M & S MOTOR
123306
KEY – WOODRUFF(1/4 X 1 NOM.)
9 120845 SEAL – NILOS LSTO STEEL DISK 3
10 145593 ROD – ADJUSTER WELDMENT
1
11
145345 ROD – ADJUSTER WELDMENT
1
12 144602
PANEL – REAR WELDMENT 1
13 172747 SKID – COMPLETE WITH REFLECTORS
1
14 115145
REFLECTOR – FLUORESCENT RED-ORANGE
1
15 115147
REFLECTOR – RED
1
16
145357
BRACKET – IDLER ARM 1
17 144652 BAR – STIFFENER 1
18 144851 DEFLECTOR – SEAL
1
19 144558 BUSHING – STEEL
1
20 144597 SEAL – BACKSHEET
1
21 165304 DRAPER – ENDLESS, DWA
1
22 37687 MOULDING 2
23 18604
PIN – COTTER 3/32 DIA. x 3/4 ZP
1
24 18671
FITTING – LUBE 1/4-28 UNF
1
25 176063 SHAFT – THREADED
4
1
26 30695 FITTING – HYDRAULIC CONNECTOR 2
27 132867 HOSE – HYDRAULIC 2
28 176077 HOSE – HYDRAULIC
1
REPAIR PARTS
4. Older units used a hex head bolt in this location. When replacing bolt with the new threaded shaft, also order one
each of nuts, items 69 and 70 for head end.
