63
See Chart Menu to select the display options.
When you access the Plotter function, your vessel, symbolized by an
isosceles triangle, is located at the center of the screen by default.
Use the
button to move around in the chart. Push the Esc button once
more to return to the initial mode with your vessel at the center of the
screen.
Other Information Displayed
In addition to your vessel and active track, you can also choose to display:
- the North
- the direct line to the active waypoint
- the vessel line to the active waypoint
- the zoom scale
- the active waypoint or all waypoints
- one or several of the 5 saved tracks
- the depth contours and sounding points
- the light sectors
- the navigation aids…
See Plotter Menu and Chart Menu.
Centering the Screen on a Waypoint
You can press the (5) button on the alphanumeric keypad at any
time to display your list of waypoints and select the one you want to
display at the center of the chart.
Note: If the selected waypoint is not displayed at the center of the
screen, check to make sure that you have not chosen to display
only the active waypoint. See Plotter Menu.
Push the Esc button to return to the initial mode with your vessel
displayed at the center of the screen.
Note: The function whereby a waypoint is centered on the chart is also
available when you are not using a full screen display (Plotter
Screen No. 2). Pressing the (5) button has no effect when
your list of waypoints is empty.
Using the Zoom
Manual Zoom
The Z- (7) and Z+ (9) buttons let you zoom in and out.
Push Z- (7) to zoom out and change to a larger scale to display fewer
details.
