85
Note: Your FX324 MAP can also be installed using the optional flush
mounting kit. The flush mounting kit must be used only when the
GPS is connected to an external antenna. Contact your Magellan
distributor for more information.
îî Connection
FX324 MAP Description FX324 MAP Wires
Power 10/36 volts Red
Power 0 volt Blue
RS232 Reference Green
RS232 Input Black
RS232 Output White
RS422 Reference Orange
RS422 Output Yellow
Power
The Fx324 MAP functions using DC supply of between 10V and 36V. It is
protected against current reversal and has a safety fuse. The blue wire
must be connected to the - on the onboard power supply and the red wire
to the +.
If you need to replace the safety fuse, always use a fuse with the following
characteristics: Type: 6.3x32 - Fast blow 2A 250V UL/CSA
Date Output or Digital Output
The FX324 MAP is equipped with two digital outputs:
An RS232 digital output (white wire) and a RS232 Reference (Green wire)
for connection to a PC.
An RS422 digital output (yellow wire) and a RS422 Reference (Orange
wire) for connection to an autopilot, a radar, a sounding machine, another
GPS, etc.
Data Input or Digital Input
The FX324 MAP has an RS232 digital input (black wire) and a RS232
Reference (Green wire) for loading waypoints from a PC and for
connecting it to an external differential correction receiver or another
GPS.
See Using Your FX324 MAP in DGPS Mode or in Slave Mode.
Connection to a PC
We recommend using the available PC connector.
