Grove Published 7-23-2020, Control # 668-02 4-83
GRT9165 OPERATOR MANUAL OPERATING PROCEDURES
7 Speedometer
Shows the crane travel speed in the selected unit of measure
(kph / mph).
8
Battery/Charging
Voltage Indicator
Shows the battery voltage when the engine is off and the charging
voltage when the engine is running.
Red Indicator - Indicates the battery voltage is less than 20V or
greater than 30V.
9
Hydraulic Oil
Temperature indicator
Shows the hydraulic oil temperature in the selected unit of measure
(°C / °F).
If indicator is yellow or red, safely stop crane operation and let
hydraulic oil cool by running engine at idle with no functions
actuated.
Item Name Symbol Description
