GRT9165 OPERATOR MANUAL SET-UP AND INSTALLATION
5
To H ois t
Lattice Insert, Boom Extension Base and Fly Sections
with Overhaul Weight
Shown at 0° Offset
Boom Extension Base and Fly Sections
with Overhaul Weight (One Part Line)
Shown at 0° Offset
FIGURE 5-23
To H oi st
To H oi s t
Boom Extension Base Section with
Overhaul Ball (One Part Line)
Shown at 0° Offset
Boom Extension Base Section
with Hook Block (Two Part Line)
Shown at 0° Offset
10040
10038
10039
10037
To H oi s t
