167
22
201
189
183
160
207
163
168
163
401
21
402
14
200
DEATH OR SERIOUS INJURY COULD RESULT
FROM SLIPPING OR FALLING
DO NOT USE TOP OF BOOM AS A WALKWAY.
7376007250
DANGER
BOTH SIDES
BOTH SIDES
BOTH SIDES
169
180
BOTH SIDES
BOTH SIDES
BOTH SIDES
BOTH SIDES
BOTH SIDES
405
BOTH SIDES
14
BOTH SIDES
SUPERSTRUCTURE ROTATION
COUNTERWEIGHT REMOVAL
DEATH OR SERIO US INJURY COULD
RESULT FROM BEIN G CRUSHED BY
MOVING MACHINERY.
CLEAR ALL PER SONNEL FROM THE
COUNTERWEIGHT AND
SUPERSTRUCTURE AREA BEFORE
REMOVING THE COUNTERWEIGHT OR
ROTATING THE SUPERSTRUCTURE.
FOLLOW THE INST RUCTIONS IN
OPERATOR’S AND SAFETY HANDBOOK.
DANGER
CRUSHING HAZARD
7376008180
7376102552
DANGER
Pressurized hydraulic oil leaks can cause
death or serious injury.
Stay clear of all hydraulic oil leaks. Relieve
system pressure and use a piece of
cardboard or paper to check for leaks. Do
not use your hand.
Fluid injected into skin must be surgically
removed within a few hours by a doctor
familiar with this type of injury or gangrene
will result.
BOOM EXTENSION HAZARD
TO AVOID DEATH OR SERIOUS INJURY:
Follow procedures in load chart, safety, and
operation manuals during erection, stowage and
use of boom extension. Install and secure all
pins properly and control boom extension
movement at all times.
7376101873
DANGER
14
13
BOOM EXTENSION HAZARD
TO AVOID DEATH OR SERIOUS INJURY:
Follow procedures in load chart, safety, and
operation manuals during erection, stowage and
use of boom extension. Install and secure all
pins properly and control boom extension
movement at all times.
7376101873
DANGER
BOOM EXTENSION HAZARD
TO AVOID DEATH OR SERIOUS INJURY:
Follow procedures in load chart, safety, and
operation manuals during erection, stowage and
use of boom extension. Install and secure all
pins properly and control boom extension
movement at all times.
7376101873
DANGER
Before removal or installation of counterweight,
read and understand instructions in the Operator’s
and Safety Handbook to avoid serious injury or death.
Outriggers must be properly extended and set and crane
level before installation or removal of counterweight or
auxiliary hoist structure.
Lifting operations are not permitted with any
counterweight on the carrier deck except for the removal
or installation of the counterweight.
Boom is not permitted over carrier deck when the boom
DQJOHLVOHVVWKDQÛDQGDQ\FRXQWHUZHLJKWLVSRVLWLRQHG
on deck.
Hookblock is not permitted to come in contact with
counterweight during removal or installation.
Travel is not permitted with any counterweight on carrier
deck.
DANGER
80015018
G7
CAUTION
Dead end lug not to be
used as tie down point
for boom during
transportation. Failure
to comply may result in
machine damage. When
the boom is secured for
transport, boom shall
not be constrained. All
securement must allow
for reasonable freedom
of movement.
G7 80061893
7376102910
G7
G7 80025216
Attention
Special lubricant has been installed in
this component. For more information
please refer to lubrication decal on
Hydraulic Reservoir or lubrication chart
in Operator's Manual.
80002505
COLD WEATHER LUBRICANT
A SYNTHETIC AGMA NO.4EP GEAR OIL
HAS BEEN USED TO REPLACE STANDARD
OIL. SEE SERVICE MANUAL FOR TYPE OF
OIL FURNISHED.
UNDER COVER, ON FRAME
AT EACH HOIST
HOOK BLOCK
80002506
COLD WEATHER LUBRICANT-
A SYNTHETIC MULTIPURPOSE GREASE
HAS BEEN USED IN PLACE OF STANDARD
GREASE. SEE SERVICE MANUAL FOR
TYPE OF GREASE REQUIRED.
164
BOTH SIDES
80101847 C3
80125573G7
X126-AUX LIMIT SWITCH
X127-WIND SPEED INDICATOR
X130-AIRCRAFT WARNING LIGHT
BOOM EXTENSION
WIRING CONNECTIONS
To Next Page
