Masimo Rad-97 Operator's Manual

Rad-97 Chapter 4: Operation
www.masimo.com 76 Masimo
SpCO Settings
From the SpCO Settings screen, access the following screens:
SpCO Alarms on page 76
In Vivo for SpCO on page 76
Trends on page 97
About Parameter Information on page 78
SpCO Alarms
From the SpCO Settings screen, access the following screens:
Options Description Alarm
Priority
Factory
Default
Settings
User Configurable
Settings
High Limit High Limit is the upper
threshold that triggers an
alarm.
High 10 2% to 98%, in steps
of 1%, or Off
When set to Off,
alarm is disabled
Low Limit Low Limit is the lower
threshold that triggers an
alarm.
Medium Off Off or 1% to 97%, in
steps of 1%
When set to Off,
alarm is disabled
Silence
Duration
Sets the amount of time
that the alarm is silenced.
NA 2 minutes 30 seconds, 1, 2, or 5
minutes
In Vivo for SpCO
In Vivo is currently not available in the U.S.A. and territories relying on FDA market
clearance.
From the In Vivo screen, access the following screens:
Options Description Factory Default
Settings
User Configurable
Settings
Enabled See In Vivo Adjustment
Overview on page 61.
Off On or Off

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
